Axicon 6100-S Linear Barcode Verifier
| Code Width | Less than 2.5" |
| Verifier Type | Linear Only |
Product Highlights
Linear Barcode Verifier, Designed for All Bar Codes Where a 3, 5, 6, 10, or 20mil Aperture is Mandatory, like UPC-A and E, EAN-8 and 13, GS1-128 and ITF-14, USB / Serial Connection, Follows the ISO15416 and ANSI X3.182 Bar Code Inspection Method, Traceable to NIST (National Institute of Standards and Technology), Automatic variable aperture (3, 5, 6, 10 & 20 mil)
Spec. Sheet
Easy-to-use Design, the Highest Level of Accuracy Achievable for Verification
Features
- Follows the ISO15416 and ANSI X3.182 Bar Code Inspection Method
- Conforms to ISO15426-1 Bar Code Verifier Specification
- Traceable to NIST (National Institute of Standards and Technology)
- Auto-discriminates between all popular symbologies
- Accurate display of the ‘X’ dimension/Magnification
- Automatic variable aperture (3, 5, 6, 10 & 20 mil)
- Multiple scan averaging
- Traditional analysis also provided
- USB 2.0 connection
- Free lifetime software upgrades
Summary
The "S" range of Axicon verifiers have a “Continuous Scan” feature. Just place the verifier over the barcode, press the trigger and slide the verifier over the code - in less than a second you can have results averaged over more than 100 scans of the code at different points in the bar height.
The Axicon 6100-S is designed for all barcodes where a 3, 5, 6, 10, or 20mil aperture is mandatory (such as UPC A & E, EAN 8 & 13, GS1-128 and ITF-14), up to 2.71” (69mm) width including quiet zones. The simple to use design reduces user error and eliminates product damage while providing the highest level of accuracy achievable for verification.
The Axicon 6100-S accuracy makes it an ideal unit for bar code audits. Proprietary software was developed to allow custom ‘User Data’ to be added to quality reports. You choose what data to collect (Typical data; press location, print density, orientation, operator name) and the information is stored in a database and printed on the quality report. Information is stored in a database and printed on the quality report.
