ID Tech Spectrum Air Card Reader

Moir Insert Reader

Intelligent OEM Module

for Magnetic Stripes RS-232, USB-HID, USB-HID-KB, USB-CDC, and Keyboard Wedge Interface

ID Tech’s Spectrum Magstripe Only Insert Reader (MOIR) is designed to read and decode up to three tracks of magnetically-encoded information. It reliably reads media conforming to ISO 7810 and 7811 standards and it reads most formats like AAMVA for driver licenses. The magnetic head is spring-loaded to ensure good contact with warped or bowed cards.

The MOIR provides many communication options: RS232 Serial, USB-CDC (virtual COM), USB-HID, USB-HID-KB, and Keyboard Wedge (PS/2). Both OPOS & JPOS support is provided. PC operating system provides the USBCDC drivers for standard operating function. Most keyboard language types are supported for keyboard wedge operation. Other drivers and support are available on the ID TECH website.

The ID Tech Hybrid Insert Reader is a fully-intelligent unit that can be configured to read all tracks or selected tracks from a magnetic stripe. It can also output data with a terminating character and up to nine prefix and/or postfix characters to match a data format expected by the host. ID TECH provides a Configuration Utility for configuration of the reader interface and the output data format. The PC based software application is available to download from the ID Tech website.

Industry compatible footprints and applications:

• Industry compatible footprints and applications.
• Chassis molded from fiber-filled engineering plastic
• Supprts magnetic head and PCB
• Bezel options - standard, metal or flush-mount
• Tri-color LED (optional)
• User-transaction confirmation
• Debris opening
