Labelmate ZCAT-10 Rewinder with Adjustable Tension Control [10.5"x12"]

SKU: ZCAT-10
|
Weight: 52 lbs.
Part Type Rewinder
Width (inches) 10.5 inch
Core Size 3.00 inch
Outer Diameter 12 inch OD

Product Highlights

Labelmate ZCAT-10, Rewinder with Adjustable Tension Control. 10.5"x12", Max. Roll Diameter: 12" (305mm), Max. Media Width: 10.5" (266mm), Core Diameter: 3" (76mm), Position: Left Side of Printer or Right Side of Printer, Core Holder: Mechanical Chuck, Full 5-Year Parts and Labor Limited Warranty, Part No. 80-203-0093

Item May Have Up to a 10-Day Lead Time. Please Contact Us for an Estimate or Quote.

Spec. Sheet

Frequently Bought Together

Labelmate ZCAT-10 Rewinder with Adjustable Tension Control. 10.5"x12".

ZCAT-10 Tensioning Rewinders are the ideal solution for sensitive inkjet printers that back-feed and/or that don’t like being tugged-on by a Rewinder. With the ZCAT-10, the printer doesn’t even know that the Rewinder is there. A free-hanging loop of material forms between the printer and the Rewinder and an optical sensor on the Rewinder starts and stops the rewind action in conjunction with the printer. Fully adjustable tension control on the Rewinder assures that the finish roll is tight and the roll edge flush.

Rewinder with Adjustable Tension Control. 10.5"x12".

  • Max. Roll Diameter: 12" (305mm)
  • Max. Media Width: 10.5" (266mm)
  • Core Diameter: 3" (76mm)
  • Position: Left Side of Printer or Right Side of Printer
  • Core Holder: Mechanical Chuck
  • Full 5-Year Parts and Labor Limited Warranty

Shipping Information

  • Size: 22"×22"×22" (560x560x560mm)
  • Weight: 52 lbs.
MSRP: $1695.00
$1483.13
